APOLLO MINI COMMANDER 110CC ATV, AUTO NO REVERSE

Age 6 Years old and up

APOLLO MINI COMMANDER 110CC ATV, AUTO NO REVERSE

Features

lubricating system : Pressure and splashEngine Oil : SAE15W/40Vehicle desc : Single seat、Chain drive、Rear wheel driveVehicle Type : GProduct Size : 47.2″×29.3″×30.9″Axle Base : 31.6″Track front : 24.2″Track rear : 21.6″Ground clearance : 3.1″Spark plug : LGD8TCCarburetor : PZ19Battery : 12V、5AhFuel Tank : 2.5LPacking Size : 44.8″×27.5″×23.2″N.W. : 165.3 lbsG.W. : 194 lbs40HQ loading : 136pcs/40’HQ



Technical Specs

 Model : AGA-10 Model series : commander Engine Type : Single cylinder 4 stroke Clutch : automatic no reverse – hand shift Displacement : 106.7cc Bore&Stroke : 52.4mm×49.5mm Compression rate : 9.7:1 MX Power : 5.0kW/8000rpm MX torque : 5.9N.m/6000rpm Idle Speed : 1500±100r/min Min.fuel consumption : ≤367g/kW·h sparking mode : CDI starting mode : Electric Fuel : RQ-93 Seat Height : 22.8″ Curb weight : 169.7 lbs Rated Payload : 143.3 lbs MAX Speed : 40km/h MINI turning radius : 98.4″ MAX gradeability : 10° Front Brake : Drum brake-handle Rear Brake : Hydraulic brake-handle Front Tire : 145/70-6 Rear Tire : 145/70-6 Tire pressure F. : 10P.S.I. Tire pressure R. : 10P.S.I. Driving Method : Chain Drive Clutch : automatic no reverse multichi
